CBK 360° AUTOMATIC TOUCHLESS CAR WASHING SYSTEM

Comes in Standard Version (US-SV) and Enhanced Version (US-EV)

If you’ve been searching for a car wash system that is safe, reliable, affordable, durable, and above all affordable and which can be used for self-service car washes and full service car washes, look no further. After years of research and development, we at CBK Car Wash Systems USA Inc. are proud to offer the CBK 360 Car Washing System in two versions: the US-EV (Enhanced) system and the US-SV (Standard) system to meet your needs.

The US-EV system delivers four different types of wash settings, while the US-SV at the basic level delivers two different type of wash settings. We are so certain of their reliability and durability that these systems come with a 3 year warranty, whereas most car wash systems on the market typically only come with a 1 year warranty. In addition, we offer 24 hour customer support to help you with your needs all day everyday.

BEST-IN-CLASS FEATURES

  • CHASSIS & HUB WASH SYSTEM

    Built-in chassis and hub wash system, pressure 80-90 Bar.

  • PRE-SOAK SPRAY

    360° rotary free wipe foam spray with uniform pressure. Industry pioneering double pipeline system WITH water and foam completely separated.

  • HIGH-PRESSURE FLUSH

    High pressure fan-shaped water polish with uniform speed, uniform pressure and uniform distance, pressure 100-200 Bar.

  • MAGIC FOAM SPRAY

    The robotic arm converts the wash fluid into mist or foam form, and sprays evenly to every part of the car body to achieve best decontamination effect.

  • TRIPLE FOAM

    Three different colors of foam are sprayed on the body of the car at the same time to form beautiful ribbons.

  • The robotic arm walks 360° around the car body, and the angle of the four corners of the robotic arm is 90°, which is closer to the vehicle and shortens the cleaning distance.

  • Equipped with the function of cleaning the chassis and wheel hub, the nozzle pressure can reach 176-198lbs.

  • Automatically adjust the ratio of a variety of liquids, including: ordinary car washing liquid, water flooding coating wax, and no-scrub car washing liquid.

  • The water pressure of the water pump nozzle can reach 220lbs, and the robot arms of the system wash the car body at a constant and uniform speed and pressure. Two pressure modes (standard/power) can be selected.

  • A macro-molecular chloride is generated in the car body, which plays a role in preventing acid rain, pollution, and ultraviolet rays.

  • The built-in air-drying system is equipped with four 5.5 kWh fans, which can effectively air-dry the whole body of the vehicle, and there is no dead angle in 360 degrees.

  • Equipped with advanced ultrasonic sensors, smart photoelectric sensors and closed-loop controllers, the system uses an accurate closed-loop detection system to detect the length of the vehicle to ensure stability, safety, and energy saving.

  • Carry out vehicle cleaning under the premise of ensuring safety, and carry out safety protection for various emergencies.

  • Guide the vehicle to park through reminding lights that allow the vehicle to avoid collision and danger.

  • When the equipment fails, the light and sound will prompt at the same time, and the equipment will stop running at the same time.

  • Through the system’s “Internet of Things” technology, complete remote startup, shutdown, reset, diagnosis, upgrade, operation, remote liquid level monitoring and other operations is possible.

  • If the device is not used for a long time, it will automatically enter the standby state, which can reduce the energy consumption of the device in the idle state by 85%.

  • When the equipment is abnormal, start the self-check and alarm procedures, identify the cause of the fault and record the fault code, which is convenient for query and maintenance.

  • Leakage protection is used to protect the staff who may get an electric shock in the event of a leakage fault. At the same time, it has overload and short-circuit protection functions, which can be used to protect the circuit and the motor from overload and short-circuit.

  • No electrical appliances are exposed to the outside of our mainframe rack, and put the control box and wires in the storage room. This ensures safety and reduces failures.

  • We set up two pipelines to spray water and foam separately, the single foam tube we designed is more than 2/3 less wasteful than the ordinary car washing machine.

  • The program is free to upgrade for life, so that your car washing machine will never be outdated.

+ NEW MOBIL DEVICE APP

FUNCTIONS

TECHNICAL PARAMETERS & PRICING

CBK US-EV (ENHANCED)

  • WARRANTY: 1 Year Labor/ 3 Years Parts

  • GROUND CONCRETE THICKNESS OF THE SITE : 8in. or more

  • WATER PUMP: 6 Motor 15KW/208V

  • AIR-DRYING MOTOR: Four 5.5KW motors/208V

  • PUMP PRESSURE: 10MPa

  • STANDARD WATER CONSUMPTION: 34-47gal / Car

  • STANDARD POWER CONSUMPTION: 0.5-1.2kWh

  • RAIL LENGTH: 29ft

  • TOTAL POWER: 15KW+25KW

  • TOTAL WEIGHT: 5,070lbs

  • POWER REQUIREMENT: 25KW, 208V - 200Amps

    Reg Price: $79,999.00

    NOW Only: $69,999.00 Until 12/31/24

    MONTHLY PAYMENT OPTION: $1,635.00

    FREE DELIVERY

Payment Option is Provided by:

CBK US-SV (STANDARD)

  • WARRANTY: 1 Year Labor/ 3 Years Parts

  • GROUND CONCRETE THICKNESS OF THE SITE : 8in. or more

  • WATER PUMP: 6 Motor 15KW/208V

  • AIR-DRYING MOTOR: Four 5.5KW motors/208V

  • PUMP PRESSURE: 10MPa

  • STANDARD WATER CONSUMPTION: 23-36gal / Car

  • STANDARD POWER CONSUMPTION: 0.5-1.2kWh

  • RAIL LENGTH: 20ft

  • TOTAL POWER: 15KW+25KW

  • TOTAL WEIGHT: 4,629lbs

  • POWER REQUIREMENT: 25KW, 208V - 200Amps

    Reg Price: $73,999.00

    NOW Only: $63,999.00 Until 12/31/24

    MONTHLY PAYMENT OPTION: $1,494.00

    FREE DELIVERY

GET A QUOTE TODAY

To get a quote, place an order, or if you have any questions, call toll-free at the number below or fill out the form below and we’ll get in touch with you shortly.

TOLL-FREE (USA): (855) 479-4-360
MAIN OFFICE: (302) 268-8881

ACCESSORIES

INSTALLATION DIAGRAM

WHEN YOU ORDER A CBK 360 SYSTEM YOU CAN ALSO ORDER OPTIONAL COMPONENTS:

  • SPECS: 5.5KW

    The fans are used for air drying when the vehicle is finally driven out of the washroom.

  • SPECS: Up to 107sq. ft.

    The door senses the vehicle and turns on and off automatically after the cars drive in and out, improving operation efficiency.

  • Used to control vehicle access.

  • The automatic mat cleaner machine washes mats with both water and foam with a clean time of 20 seconds per mat.

  • SPECS: 22-V / 50HZ / 50W

  • Motor Power: 2.2KW
    Water Tank: 2.6 -5.2gal
    Water Pressure: 1,137-1,422psi (pounds per square)

  • Waterproof, anti-slip, common floor for car wash. Cars drive onto the ground grill to begin the washing process.

  • The Pre-Soak cleaner has a super-comprehensive decontamination ability with the capability to quickly penetrate, decompose, and soften dirt on cars

    4.7g bucket

  • This wax can quickly remove 80% of the water on the car body after washing to enhance the gloss of the car paint.

    4.7g bucket

  • This foam can quickly decontaminate and remove dirt from the surface of the car.

    4.7g bucket

WE BELIEVE IN EXCEPTIONAL CUSTOMER SERVICE.

That’s why when you become a CBK car wash system owner, you also get to enjoy our 360 bundle of dedicated services from us to support you throughout the lifecycle of your system. That’s our promise.

360 24 HOUR CUSTOMER SUPPORT SERVICE

Installation Support
·
Technical Operations Support
·
Spare Parts Support

Training Support
·
Free System Upgrade Services
·
Equipment Support
